Specifications
Additional information
Features
Description
- Amplification: Class D, 200 W RMS
- Loudspeaker: 8″ coaxial with bass driver and 1″ compression driver
- Dispersion: 75° x 75° horizontal x vertical
- Frequency response: 50 – 20,000 Hz
- Max. SPL (@ 1 m): 121 dB
- Dimensions: 275 x 295 x 404 mm (L x W x H)
- Net weight: 10 kg
- Power supply: 220 – 240 V AC, 50 Hz SMPS switching, USB port for 5 V 2.1 A charging
- Lithium battery: 14.8 V, 6,600 mAh, 97 Wh
- Autonomy: 12 hours in normal use, 6 hours at clip limit level
- Connectors :
- 2 XLR/jack combo inputs with Line/Mic switch, reverb
- 2 XLR/jack combo inputs with Line/Guitar switch, reverb and chorus
- 1 Aux input / Bluetooth 5.0
- Releases :
- 1 Mix OUT on XLR
- 1 headphone output
- 1 Bluetooth TWS output
- Features :
- Multifunction knob for adjusting volume, treble, midrange, bass and effects
- Input level selection and 48 V phantom power supply
- DSP with position presets (stand, monitor, floor)
- Separate headphone volume
- Overall volume
- Construction and ergonomics :
- ABS body
- Integral metal grille
- Power/Charge/Clip LEDs
- Top handle
- 36 mm base for stand
- Rubber pads on sides and bottom
Download
